Tekin Redline Gen3 Modified Sensored Brushless Motor (10.5T)

Tekin Redline Gen3 Modified Sensored Brushless Motor (10.5T)
Price:
NZ$ 189.00 including GST
TT2708
In stock
Purchase Qty:


Tekin’s third generation motors are re-engineered from the ground up resulting in a smaller, lighter and faster sensored motor. On Road or Off, the new GEN3 handles the task in stride, delivering the smooth power across all RPMs that you’ve come to expect from a Tekin motor. Much more than a re-hash and new look, the GEN3 Redline Sensored Motor is now ready for any situation and able to create the speed you need to win.

The GEN3 21.5T, 17.5T and 13.5T are available in an RPM version as well as the standard versions. Designed for applications where higher RPM is more beneficial than torque, these motors are perfect for 1/12 and touring car racing classes.

The GEN3 modified group of motors are custom tuned with rotor sizes to give you the performance needed for your application. The 21.5T down to 8.5T group come standard with 12.5mm performance rotors and the 7.5T to 2.5T group are equipped with a 13mm rotor for that extra torque needed in modified racing.

Input Voltage: 2S - ALL

                         3S - 10.5 and up

Weight: 5.7oz / 161g

Shaft Dimensions: 3.2mm (1/8") x 15.3mm

Motor Diameter: 35.85mm / 1.40"

Motor Length: 50mm / 1.909"

Bearing Dimensions: Front: 4x13x5mm

                                     Rear: 1/8x3/8x5/32"

Rotor Size: 12.3mm - 25.5T

                   12.5mm - 21.5T rpm* / 17.5T rpm / 13.5T rpm / 21.5T

                                   17.5T / 13.5T / 10.5T / 9.5T / 8.5T

                    13mm - 7.5T / 6.5T / 5.5T / 4.5T / 4T / 3.5T / 2.5T

                    13mm Torque - 3.5T / 2.5T

 Rebuildable: Yes



*RPM = High RPM On Road Version



OFF ROAD



 1:10 2WD Buggy

 1:10 2WD Truck

 1:10 2WD Short Course

 1:10 4WD Buggy

 1:10 4WD Truggy



ON ROAD



 1:12 2WD Pan Car

 1:10 2WD Pan Car

 1:10 World GT

 1:10 Formula 1

 1:10 4WD Touring Car

 1:10 Drift



OVAL



 1:10 2WD

 1:10 SK Car

 1:10 Stock Car

 1:10 Winged Sprint

 1S LiPo Classes

 CNC Machined 6061-T6 Billet Aluminum Heat Sink Can

 Neodymium Sintered Magnet

 Precision Engineered for Maximum Energy Conversion

 High Purity Copper Windings Maximize Conductivity

 Low Resistance, High Power Solder Tabs

 Gold-plated Solder Posts for Easy Wire Replacement

 Dual-Plug Sensor Wire Harness for all Sensored and Sensorless systems

 Anodized End-bell plates maximize corrosion and wear resistance

 High RPM Precision Bearings

 Rebuild-able Design

 Solder-less Sensor PCB replacement

 Adjustable Timing

Standard and RPM versions
