Outboard Drive System Gear Driven + SSS Motor

Outboard Drive System Gear Driven + SSS Motor
SSS Brushless Motor 3660-2075KV for P1, F1
Price:
NZ$ 420.00 including GST


or four payments of $105.00 with
Afterpay Payment Offer Learn More

B54210
Available to order Please Contact Us
Purchase Qty:


TFL Outboard Drive System Gear Driven SSS Brushless Motor 3660-2075KV


Comes with SSS 3660 2075Kv

Drive Specs for SSS Motor Version:
TFL SSS 3660 with 4mm male connectors.
Motor diameter: 36mm
Motor length: 60mm
2075Kv with 5mm Shaft
Installed metal water jacket.
185mm from bottom of skeg to top of outboard cover.
Cover is 55mm wide
550 Grams(approx) with brushless motor.

280 Grams(approx) without brushless motor.
Drive: 4mm Propeller shaft, requires drive dog style propellers.
Fits upto 48mm Prop not included
Gear driven

Requires:
Everything besides the outboard unit.
Suggest esc size, 90amp or 150amp.

2s or 3s maximum, 40c 4000 to 5000mah lipo pack.
Propeller for 4mm prop shaft, which diameter prop will depend on the application.
4mm Female Bullet Connectors
